Specifications and Price

Your bike in detail

Inspired, refined and reborn.

£9 799

CB1100 EX 2019 key features

CB1100 EX 2019 Specifications

Show specifications

  • Engine
    Bore × Stroke (mm) 73.5 x 67.2
    Carburation PGM-FI electronic fuel injection
    Compression Ratio 9.5:1
    Engine Displacement (cc) 1140
    Engine Type (cm³) Inline four-cylinder, air and oil-cooled, DOHC
    Max. Power Output 66kW/7,500rpm (95/1/EC)
    Max. Torque 91Nm/5,500rpm (95/1/EC)
    Starter Electric
    C02 Emissions (g/km) 123
    Oil Capacity (Litres) 4.9l/4.4l
  • Wheels
    Suspension Front 41mm conventional fork (SDBV) with adjustable spring preload
    Suspension Rear Twin shocks with adjustable spring preload
    Tyre Size Front 110/80 R18
    Tyre Size Rear 140/70 R18
    Wheels Front 18in x 2.50MT Wire spoke
    Wheels Rear 18in x 4.00MT Wire spoke
  • Dimensions and Weights
    Battery Capacity (VAh) 12V 11.2Ah
    Caster Angle 27°
    Dimensions (L×W×H) (mm) 2,200 x 830 x 1130mm
    Frame type Double steel cradle
    Fuel Tank Capacity (Litres) 16.8 litres
    Ground Clearance (mm) 135mm
    Kerb Weight (kg) 255kg
    Seat Height (mm) 790mm
    Trail (mm) 114mm
    Wheelbase (mm) 1,490mm
  • Transmission
    Clutch Wet, multiplate
    Final Drive Chain
    Transmission Type 6-speed
  • Instruments and Electrics
    Headlights LED
    Tail Light LED
