Specifications

Your bike in detail

EM1 e:


£3,299.00

Matte Ballistic Black Metallic

Choose colour (3)

EM1 e: 2023 key features

EM1 e: 2023 Specifications ▲

Show specifications

  • Engine
    Max. Power Output (kW) 1.7 kW
    Max. Torque (Nm) 90 Nm
    Power Consumption rate (Wh / km) 47 Wh/km
    Electric Range (km) 30km
  • Wheels
    Brakes Front Disk
    Brakes Rear Drum
    Tyre Size Front 90/90-12
    Tyre Size Rear 100/90-10
    Wheels Front Cast Type
    Wheels Rear Composite
  • Dimensions and Weights
    Dimensions (L×W×H) (mm) 1860mm x 680mm x 1080mm
    Load Capacity 180KG
    Seat length 590mm
    Seating Capacity 2
  • Instruments and Electrics
    Instruments LCD
    USB socket Type A
    Tail Light LED
    Security System Immobiliser
  • Additional Features
    Climbing Angle 12°@RW 55kg / 10°@RW75kg
  • EV Motor
    Type In-wheel 3-phase motor, Brushless
    Range Per Mode 48km - Econ Mode.
    Noise Level N/A
  • EV Battery
    Type Lithium ion
    Fixing Type Removable
    Technology Mobile Power Pack e:
    Weight 10.2 kg
    Dimensions 298mm x 177.3mm x 156.3mm
    Rated Power 270W
    Lifecycle >2,500**
    EV Battery Charger Dimensions H227×L434×W244mm
    EV Battery Charger Weight 5.3kg
  • Brakes
    ABS Type 1 channel CBS
  • Electrical System
    Number of Batteries 1
    Nominal Voltage (V) 50.3V
    Capacity (kW) 26.1 Ah
    Charger Type(s) Off-board type - Single-phase AC100-240V 50/60Hz
    Charging time 0% to 100% 6 hours**
    Charging Time 20% to 80% 160 minutes**
  • Rider Aids
    Selectable Riding Modes (number and type) Standard / Econ
  • Lighting
    Headlight / Taillight LED
  • Chassis
    Frame Type Under Bone Type
    Wheelbase (mm) 1300mm
    Seat Height (mm) 740mm
    Ground Clearance (mm) 135mm
    Caster Angle (degrees) 27 deg
    Trail (mm) 77 mm
    Turning radius (m) 1.9m
    Kerb Weight (kg) (With Battery) 95kg
  • Suspension
    Suspension Front: Type Telescopic
    Suspension Rear: Type Twin

▲

**Figures obtained under internal test conditions. The Honda Mobile Power Pack e: battery’s performance is influenced by several factors including type of usage and usage environment. Battery charging time, number of charges and range are based on Honda’s estimated figures from internal testing. Figures are shown for reference only, and not guaranteed.
