Specifications and Price
Specifications
-
Bore × Stroke (mm)
78 × 54.2
-
Carburation
PGM FI electronic fuel injection
-
Compression Ratio
10,5 : 1
-
Engine Displacement (cc)
258.9 cm3
-
Engine Type
Single cylinder, 4 strokes, 4 valves, SOHC, liquid cooling
-
Starter
Kick
-
Throttle Bore
28 mm
-
Oil Capacity (Litres)
Engine: 0.6 litres, Transmission: 0.57 litres
-
Brakes Front
Hydraulic disc 185 x 3.5 mm with 4 piston monobloc caliper and sintered metal pads
-
Brakes Rear
Hydraulic disc 183 × 3.5 mm dual-piston caliper
-
Suspension Front
Telescopic fork TECH 39mm, adjustable in preload and extension. 190mm travel.
-
Suspension Rear
Pro-Link with damper R16V system, adjustable for pre-load, extension. 170mm travel
-
Tyres Front
80/100 21 (Dunlop)
-
Tyres Rear
120/100 R18 (Dunlop)
-
Wheels Front
21 × 1,60
-
Wheels Rear
18 × 2,15
-
Caster Angle
23°
-
Dimensions (L×W×H) (mm)
2,035 x 835 x 1,160 mm
-
Frame type
Aluminium Twin Tube
-
Fuel Tank Capacity (Litres)
4.3 litres
-
Ground Clearance (mm)
325 mm
-
Seat Height (mm)
905 mm
-
Weight (kg)
82 kg
-
Wheelbase (mm)
1,335 mm
-
Clutch
Wet multiplate
-
Clutch Operation
Hydraulic
-
Final Drive
Chain
-
Gearbox
5 speed constant mesh
