Specifications and Price
Specifications
-
Clutch
Wet multiplate, assisted slipper
-
Headlights
LED
-
Seat Height (mm)
825mm
-
Instruments
5" TFT
-
Bore × Stroke (mm)
76mm × 55.1mm
-
Carburation
Port fuel injection
-
Compression Ratio
11.7
-
Engine Displacement (cc)
1000cc
-
Engine Type
Liquid-cooled, DOHC inline 4-cylinder
-
Max. Power Output
110.1kW / 11,000rpm
-
Max. Torque
102Nm / 8,750rpm
-
Starter
E-Starter
-
C02 Emissions (g/km)
140g / km
-
Oil Capacity (Litres)
Lower 3.0 L / Upper 3.5 L
-
Max Speed
200 km/h
-
ABS System
2 channel 6-axis IMU-based Cornering ABS
-
Brakes Front
Nissin 4 piston radial calipers,twin 310mm discs
-
Brakes Rear
Nissin single caliper, single 240 mm disc
-
Suspension Front
Electronically controlled suspension EERA manual preload adjuster 130mm suspension stroke
-
Suspension Rear
Electronically controlled suspension EERA electronic preload adjuster 144mm suspension stroke
-
Tyres Front
120/70ZR17M/C (58W)
-
Tyres Rear
180/55ZR17M/C (73W)
-
Wheels Front
17M/C x MT3.50
-
Wheels Rear
17M/C x MT5.50
-
Battery Capacity (VAh)
12V 9.1Ah
-
Caster Angle
25
-
Dimensions (L×W×H) (mm)
2135 x 930 x 1290 mm
-
Frame type
Diamond frame, Steel
-
Fuel Tank Capacity (Litres)
21 L
-
Fuel Consumption
6l / 100km
-
Ground Clearance (mm)
135 mm
-
Kerb Weight (kg)
229kg + 12.5kg Panniers (total weight 241.5kg)
-
Seat Height (mm)
825mm
-
Trail (mm)
106.3 mm
-
Wheelbase (mm)
1465 mm
-
Turning Radius
3.2 m
-
Noise Level
97
-
Clutch
Wet multiplate, assisted slipper
-
Final Drive
Chain
-
Transmission Type
6 Speed
-
Quick Shifter
Yes
-
Headlights
LED
-
Instruments
5" TFT
-
Tail Light
LED
-
Connectivity
Roadsync
-
USB Socket
USB-C
-
Self Cancelling Indicators
Yes
-
Cruise Control
Yes
-
Riding Modes
4 modes (Std, Rain,Sport, Tour) + 1 User mode
-
Additional Features
Emergency Stop Signal (ESS), Wheelie Control, 5-stage manually adjustable screen, grip heaters, main stand, panniers
-
Type
AGM
Built for Joy, Backed by Tech (17)
Discover the technology and rider aids driving Honda’s performance, safety and control.
HSTC Honda Selectable Torque Control
Honda Selectable Torque Control (HSTC) is a system that detects rear wheel spin and electronically adjusts engine torque to ensure traction and stable handling characteristics are maintained. On some models, the levels of HSTC intervention can be adjusted to suit rider preference and riding conditions. The levels of HSTC also form part of the selectable riding modes.
Cornering ABS
Cornering ABS is a system that controls the ABS according to bank angle. The system operates from information form the Inertial Measurement Unit (IMU) that actively measures the angle and rate of the motorcycle acceleration for yaw, roll and pitch. This information is then used to control braking pressure to ensure balanced deceleration during cornering and reduced occurrence of unintentional bike behaviour whilst cornering and braking.
HISS Honda Ignition Security System
Honda Ignition Security System (HISS) is a motorcycle immobiliser system that has a microchip embedded in the original key and is programmed with a coded password that is picked up by an antenna and communicated it to an ECU. The ECU checks the programmed code number and only allows the engine to start when the code numbers match. Even if a duplicate key of exactly the same shape as the original key is used, the engine cannot be started unless the built-in microchip code matches.
Honda Smart Key
Honda Smart Key brings the convenience of keyless entry to the motorcycle world. This system improves security and convenience as the rider can keep the key fob in their pocket whilst operating the motorcycle.
Honda RoadSync
Honda RoadSync enables full connectivity of the motorcycle through the Honda RoadSync app via a smartphone. This gives the rider access to calling, messaging and music via Bluetooth.
Cruise Control
Cruise control enables precise cruising speed control and relieves prolonged use of the throttle grip during long rides and when touring on long straight roads for improved rider comfort and reduced fatigue.
Self-cancelling direction indicators
Self cancelling direction indicators improve safety by automatically switching off the direction indicators after the turning manoeuvre is complete.
Manual Transmission
Honda motorcycles using manual transmission are equipped with 5 or 6 speed constant-mesh transmission. The drive and driven gears are always mated together but rotate freely on a gear shaft until locked by a toothed sliding collar. This ensures smooth and sequential gear changing.
Electronic suspension
The electronic suspension system actively adjusts damping characteristics to suit the riding conditions. On some of the adventure and tourer models the rider is able to use the meter to select if a pillion and or luggage is being carried, the system then automatically adjusts the damping to suit.
ESS Emergency Stop Signal
Emergency Stop Signal ESS is a safety system that alerts road users that the motorcycle is in an emergency braking situation by flashing the direction indicators during hard or sudden braking.
TBW Throttle By Wire
The Throttle By Wire (TBW) systems use electronics to control opening and closing of the throttle valves and eliminates the mechanical connection between the throttle grip and throttle valves. TBW enables the PGM-FI system to precisely control throttle opening throughout the RPM range to delivery controlled and progressive torque. It also enables the use of rider aid systems such as, selectable riding modes, Honda Selectable Torque Control (HSTC), wheelie mitigation and selectable levels of power and engine braking.
Heated hand grips
Heated grips improve rider comfort and control during cold conditions and are now fitted as standard on some models and available as a genuine Honda accessory on much of the range.
Selectable riding modes
Selectable riding modes enable the rider to select pre-set and customisable user modes. These modes alter the levels of power delivery, HSTC and engine braking to suit the rider preference or riding conditions.
Quick shifter
A quick shifter enables clutch less shifting to provide more sporty and engaging riding characteristics. Additionally it offers smoother gear changing when carrying a pillion.
6-Axis IMU
The 6-axis Inertial Measurement Unit (IMU) enables precise measurement of the angle and rate of the motorcycle acceleration for yaw, roll and pitch. This enables the use of rider aid and safety systems such as cornering ABS and rear wheel lift control.
TFT screen
Thin Film Transistor (TFT) technology is now integrated into the meter on many of the Honda motorcycle and scooter range. This type of colour display provides clear and concise user information and integrates touch screen technology on some models.
LED Headlights
LED lights use Light Emitting Diode Technology to provide clear and intensive lighting to improve visibility and visual presence as well as benefiting from their low consumption properties.
