Specifications and Price
CB125R 2026
£4,799
Matte Rock Grey
Specifications
CB125R 2026
From
£4,799
Engine
- Carburation PGM-FI electronic fuel injection
- C02 Emissions (g/km) 50 g/km
- Engine Displacement (cc) 124.9cc
- Compression Ratio (X:1) 11.3:1
- Max. Power Output (kW @ rpm) 11kW / 10000rpm
- Max. Torque (Nm @ rpm) 11.6Nm / 8000rpm
- Oil Capacity (L) 1.5L
- Bore × Stroke (mm) 57.3mm x 48.4mm
- Engine Type Liquid-cooled 4-stroke 4-valve DOHC single cylinder
- Starter Electric
Wheels
- Brakes Front 296mm disc with hydraulic dual-piston brake caliper and Radial mount Nissin 4-piston caliper
- Brakes Rear 220mm disc with hydraulic single-piston brake caliper
- Tyre Size Front 110/70R17M/C 54H
- Tyre Size Rear 150/60R17M/C 66H
- Wheels Front 17M/C x MT3.00
- Wheels Rear 17M/C x MT4.00
Dimensions and Weights
- Fuel Tank Capacity (Litres) 10.1L
- Fuel Consumption 45.5km/L (WMTC Mode)
- Dimensions (L×W×H) (mm) 2015mm x 820mm x 1055mm
Transmission
- Gearbox 6-speed
Instruments and Electrics
- Instruments 5in TFT colour meter
- Tail Light LED
Drivertrain
- Clutch Type Wet, multiplate with coil springs
- Final Drive O-ring sealed chain
Brakes
- ABS Type Front & rear independent ABS with IMU
Lighting
- Headlight / Taillight LED
- Battery Capacity (V / Ah) YTZ6V 12V 5Ah MF
Chassis
- Frame Type Inner pivot diamond frame
- Wheelbase (mm) 1345mm
- Seat Height (mm) 816mm
- Ground Clearance (mm) 140mm
- Caster Angle (degrees) 24.2°
- Trail (mm) 90.2mm
- Turning radius (m) 2.3m
- Kerb Weight (kg) 130kg
Suspension
- Suspension Front: Type 41mm SFF-BP USD forks
- Suspension Rear: Type Single-damper
