Your bike in detail

CB125F 2024


CB125F 2024 key features

CB125F 2024 Specifications

Show specifications

  • Engine
    Bore × Stroke (mm) 50x63.1
    Carburation PGM-FI electronic fuel injection
    Compression Ratio 10.0:1
    Engine Displacement (cc) 124cc
    Engine Type Air cooled 4-stroke 2-valves OHC single cylinder
    Max. Power Output 8 kW / 7,500 rpm
    Max. Torque 10.9 Nm / 6,000 rpm
    Starter Electric
    C02 Emissions (g/km) 34 g/km
    Oil Capacity (Litres) 1.0
  • Wheels
    Brakes Front 240mm single disc with 2 piston caliper
    Brakes Rear 130mm drum
    Suspension Front 30mm telescopic
    Suspension Rear Dual shocks – 5 stage preload
    Tyre Size Front 80/100 18M/C
    Tyre Size Rear 100/80 18M/C
    Wheels Front 18in five spoke aluminium
    Wheels Rear 18in five spoke aluminium
  • Dimensions and Weights
    Battery Capacity (VAh) 12V-5Ah
    Caster Angle 26°
    Dimensions (L×W×H) (mm) 2015 x 750 x 1100
    Frame type Tubular steel
    Fuel Tank Capacity (Litres) 11L
    Fuel Consumption 66.7 km/L
    Ground Clearance (mm) 160 mm
    Kerb Weight (kg) 117KG
    Seat Height (mm) 790 mm
    Trail (mm) 92.4 mm
    Wheelbase (mm) 1280
    Turning Radius 2.04m
    Noise Level Lurban - 71.8dB, Lwot - 73.5dB
  • Transmission
    Clutch Wet, multiplate with coil springs
    Final Drive Chain
    Gearbox 5 speed
    Transmission Type Manual 5-speed
  • Instruments and Electrics
    Headlights LED
    Instruments LCD meter with Speedometer, milometer, fuel gauge, rpm counter, gear position indicator
    Tail Light LED
