Specifications and Price
Change model
-
Graphite Black
-
Pearl Horizon White
-
Grand Prix Red
-
Matte Gunpowder Black Metallic
-
Pearl Himalayas White
-
Grand Prix Red
Specifications
-
Connectivity
Roadsync
-
Transmission Type
6-speed
-
Bore × Stroke (mm)
67 mm x 66.8 mm
-
Carburation
PGM FI electronic fuel injection
-
Compression Ratio
10.7:1
-
Engine Displacement (cc)
471 cc
-
Engine Type
Liquid-cooled 4-stroke DOHC parallel twin
-
Max. Power Output
35 kw (47hp) at 8,500 rpm
-
Max. Torque
43 Nm at 6,500 rpm
-
Starter
Electric
-
C02 Emissions (g/km)
80 g/km
-
Oil Capacity (Litres)
3.2 L
-
Max Speed
176 km/h
-
ABS System
2-channel
-
Brakes Front
Dual 296 mm x 4 mm disc with Nissin radial-mount four piston calipers
-
Brakes Rear
Single 240mm x 5 mm disc with single piston caliper
-
Suspension Front
Showa 41mm SFF-BP USD forks,
-
Suspension Rear
Prolink mono with 5 stage preload adjuster, steel hollow cross swingarm
-
Tyres Front
120/70ZR17M/C (58W)
-
Tyres Rear
160/60ZR17M/C (69W)
-
Wheels Front
17M/C X MT3.5 5Y-Spoke Cast Aluminium
-
Wheels Rear
17M/C X MT4.5 5Y-Spoke Cast Aluminium
-
Battery Capacity (VAh)
12 V 7.4 Ah
-
Caster Angle
25.5°
-
Dimensions (L×W×H) (mm)
2,080 mm x 800 mm x 1,060 mm
-
Frame type
Steel diamond
-
Fuel Tank Capacity (Litres)
17.1 L
-
Fuel Consumption
3.5L/100km
-
Ground Clearance (mm)
145 mm
-
Kerb Weight (kg)
191 kg
-
Seat Height (mm)
785 mm
-
Trail (mm)
102 mm
-
Wheelbase (mm)
1,410 mm
-
Turning Radius
2.7 m
-
Noise Level
89 dB (A)
-
Clutch
Wet multiplate, Assisted slipper clutch, Honda E-Clutch
-
Final Drive
Chain
-
Transmission Type
6-speed
-
Headlights
LED
-
Instruments
5 inch TFT Meter with customisable layout, including but not limited to Speedometer, Tachometer, Clock, Gear position, Shift UP Indicator
-
Tail Light
LED
-
Connectivity
Roadsync
-
Additional Features
ESS
-
Type
AGM
-
Connectivity
Honda RoadSync
-
12v Socket
Optional
-
Transmission Type
6-speed Manual
-
Bore × Stroke (mm)
67mm x 66.8mm
-
Carburation
PGM-FI electronic fuel injection
-
Compression Ratio
10.7:1
-
Engine Displacement (cc)
471cc
-
Engine Type
Liquid-cooled 4-stroke DOHC parallel twin
-
Max. Power Output
35kW [47hp] / 8,600rpm
-
Max. Torque
43Nm/6,500rpm
-
Starter
Electric
-
Throttle Bore
34
-
C02 Emissions (g/km)
80 g/km
-
Oil Capacity (Litres)
3.2L
-
Brakes Front
Dual 296 mm x 4 mm disc with Nissin radial-mount four piston calipers
-
Brakes Rear
Single 240 mm x 5 mm disc with single piston caliper
-
Suspension Front
Showa 41mm SFF-BP USD forks
-
Suspension Rear
Prolink mono with 5 stage pre-load adjuster, Steel hollow cross swingarm
-
Tyre Size Front
120/70ZR17M/C (58W)
-
Tyre Size Rear
160/60ZR17M/C (69W)
-
Wheels Front
17M/C X MT3.5 5Y-Spoke Cast Aluminium
-
Wheels Rear
17M/C X MT4.5 5Y-Spoke Cast Aluminium
-
Battery Capacity (VAh)
12v 7.4Ah
-
Caster Angle
25.5°
-
Dimensions (L×W×H) (mm)
2,080mmX800mmX1,060mm
-
Frame type
Steel diamond
-
Fuel Tank Capacity (Litres)
17.1L
-
Fuel Consumption
28.6km/L / 3.5l/100km
-
Ground Clearance (mm)
145
-
Kerb Weight (kg)
188
-
Seat Height (mm)
785
-
Trail (mm)
102mm
-
Wheelbase (mm)
1,410mm
-
Turning Radius
2.7
-
Noise Level
Lurban 73.5dB Lwot 76.8dB
-
Clutch
Wet multiplate, Assisted slipper clutch
-
Final Drive
Chain
-
Transmission Type
6-speed Manual
-
Headlights
LED
-
12v Socket
Optional
-
Instruments
5in TFT Meter with customisable layout, including but not limited to Speedometer, Tachometer, Clock, Gear position, Shift UP Indicator.
-
Tail Light
LED
-
Connectivity
Honda RoadSync
-
Emergency Stop Signal
Yes
-
Security
HISS
