Specifications and Price

Change model
  • Montesa Cota 4RT 260R 2026 Fighting Red Fighting Red
  • Montesa Cota 4RT 260R 2024 Black Black

Specifications

Montesa Cota 4RT 260R 2026

£6,899.00

  • Bore × Stroke (mm)

    78 x 54.2

  • Carburation

    Electronic fuel injection PGM-FI

  • Compression Ratio

    10.5 : 1

  • Engine Displacement (cc)

    258.9

  • Engine Type

    Single, 4-stroke, 4 valves, SOHC, liquid cooled

  • Starter

    Kick

  • Brakes Front

    185 × 3.0 mm hydraulic disc with 4-piston caliper and sintered metal pads

  • Brakes Rear

    150 × 3.0 mm hydraulic disc with 2-piston caliper and sintered metal pads

  • Suspension Front

    39 mm SHOWA telescopic fork with pre-load, rebound and compression adjustment. 158mm stroke

  • Suspension Rear

    Pro-Link system, R16V shock with compression and rebound adjustment. 170 mm stroke

  • Tyres Front

    80/100 21 (Dunlop)

  • Tyres Rear

    120/100 R18 (Dunlop)

  • Wheels Front

    Aluminium rims / wire spokes

  • Wheels Rear

    Aluminium rims / wire spokes

  • Caster Angle

    23°

  • Dimensions (L×W×H) (mm)

    2020 × 840 × 1135 mm

  • Frame type

    Diamond, aluminium twin spar

  • Fuel Tank Capacity (Litres)

    1.8 litres

  • Ground Clearance (mm)

    335 mm

  • Seat Height (mm)

    650 mm

  • Trail (mm)

    63 mm

  • Wheelbase (mm)

    1,320 mm

  • Clutch

    Wet, multiplate with coil springs

  • Final Drive

    Roller chain

  • Gearbox

    5-speed

  • Ignition System

    Electronic, digital transistor

Montesa Cota 4RT 260R 2024

  • Bore × Stroke (mm)

    78 x 54.2

  • Carburation

    Electronic fuel injection PGM-FI

  • Compression Ratio

    10.5 : 1

  • Engine Displacement (cc)

    258.9

  • Engine Type

    Single, 4-stroke, 4 valves, SOHC, liquid cooled

  • Starter

    Kick

  • Brakes Front

    185 × 3.0 mm hydraulic disc with 4-piston caliper and sintered metal pads

  • Brakes Rear

    150 × 3.0 mm hydraulic disc with 2-piston caliper and sintered metal pads

  • Suspension Front

    39 mm SHOWA telescopic fork with pre-load, rebound and compression adjustment. 158mm stroke

  • Suspension Rear

    Pro-Link system, R16V shock with compression and rebound adjustment. 170 mm stroke

  • Tyres Front

    80/100 21 (Dunlop)

  • Tyres Rear

    120/100 R18 (Dunlop)

  • Wheels Front

    Aluminium rims / wire spokes

  • Wheels Rear

    Aluminium rims / wire spokes

  • Caster Angle

    23°

  • Dimensions (L×W×H) (mm)

    2020 × 840 × 1135 mm

  • Frame type

    Diamond, aluminium twin spar

  • Fuel Tank Capacity (Litres)

    1.8 litres

  • Ground Clearance (mm)

    335 mm

  • Seat Height (mm)

    650 mm

  • Trail (mm)

    63 mm

  • Wheelbase (mm)

    1,320 mm

  • Clutch

    Wet, multiplate with coil springs

  • Final Drive

    Roller chain

  • Gearbox

    5-speed

  • Ignition System

    Electronic, digital transistor
