MSX125

Specifications and Price

Your bike in detail

MSX125 2023

: £3,899.00

Splendid Blue

Choose colour (3)

MSX125 2023 key features

MSX125 2023 Specifications ▲

Show specifications

Bore × Stroke (mm)	50.0 x 63.1
Carburation	PGM-FI electronic fuel injection
Compression Ratio	10.0:1
Engine Displacement (cc)	124
Engine Type	Air-cooled 2-valve single cylinder
Max. Power Output	7.4kW / 7,250 rpm
Max. Torque	11.1Nm / 6,000 rpm
Starter	Electric
C02 Emissions (g/km)	34 g/km
Oil Capacity (Litres)	1.1 L

Brakes Front	Single 220mm disc with hydraulic dual-piston brake caliper
Brakes Rear	Single 190mm disc with hydraulic single-piston brake caliper
Suspension Front	USD Front Forks, 31mm
Suspension Rear	Mono shock, steel square pipe swingarm
Tyre Size Front	120/70R12 51L
Tyre Size Rear	130/70R12 56L
Wheels Front	12 X MT2.75 5-Spoke Aluminium Cast
Wheels Rear	12 X MT 3.50 5-Spoke Aluminium Cast

Dimensions and Weights

Battery Capacity (VAh)	12V 3.5Ah
Caster Angle	25°
Dimensions (L×W×H) (mm)	1760 x 720 x 1015
Frame type	Steel mono-backbone frame
Fuel Tank Capacity (Litres)	6 litres
Fuel Consumption	66.7 km/l
Ground Clearance (mm)	180 mm
Kerb Weight (kg)	103 kg
Seat Height (mm)	761 mm
Trail (mm)	81 mm
Wheelbase (mm)	1200 mm
Turning Radius	1.9 metres

Clutch	Wet multiplate
Final Drive	Chain
Transmission Type	5-speed

Instruments and Electrics

Headlights	LED
Instruments	LCD digital dash with speedometer, twin trip meters, fuel gauge and clock.
Tail Light	LED
