Specifications and Price
Change model
-
Ross White
-
Graphite Black
-
Pearl Deep Mud Grey
-
Ross White
-
Matte Ballistic Black Metallic
-
Matte Iridium Grey Metallic
Technical Specifications
Key Features
-
Connectivity
RoadSync
-
Self Cancelling Indicators
Yes
-
12v Socket
No
-
USB Socket
Type - C
-
Quick Shifter
No
Engine
-
Bore × Stroke
87 mm x 63.5 mm
-
Carburation
PGM-FI Fuel Injection
-
Compression Ratio
11
-
Engine Displacement (cc)
755 cc
-
Engine Type
Liquid-cooled OHC 4-stroke 8-valve Parallel Twin with 270° crank and uni-cam
-
Max. Power Output
67.5 kW at 9,500 rpm
-
Max. Torque
75 Nm at 7.250 rpm
-
Starter
E-Starter
-
C02 Emissions (g/km)
102 g/km
-
Oil Capacity (Litres)
3.9 L
-
Max Speed
195 km/h
Wheels
-
Brakes Front
Axial mounted two-piston brake caliper, 310 mm floating double disc
-
Brakes Rear
Single piston caliper, 256 mm single disc
-
Suspension Front
Showa 43 mm SFF-CA USD, 200 mm travel
-
Suspension Rear
Monoshock damper, Prolink swingarm, 190 mm travel
-
Tyres Front
90/90-21M/C 54H
-
Tyre Size Rear
150/70R18M/C 70H
-
Wheels Front
21 x 2.15 Stainless spoke, Aluminium rim, Tube type
-
Wheels Rear
18M/C x MT4.00 Stainless spoke, Aluminium rim, Tube type
Dimensions and Weights
-
Battery Capacity (VAh)
12 V 9.1 Ah
-
Caster Angle
27°
-
Dimensions (L×W×H) (mm)
2,325 mm x 838 mm x 1,455 mm
-
Frame type
Diamond Steel Frame
-
Fuel Tank Capacity (Litres)
16.9 L
-
Fuel Consumption
4.3 L/100km
-
Ground Clearance (mm)
210 mm
-
Kerb Weight (kg)
210 kg
-
Seat Height (mm)
850 mm
-
Trail (mm)
111 mm
-
Wheelbase (mm)
1,560 mm
-
Turning Radius
2.6m
-
Noise Level
max. 79.4 dB
Transmission
-
Clutch
Wet multiple, Assisted slipper clutch
-
Final Drive
Chain
-
Transmission Type
6-speed Manual Transmission
-
Quick Shifter
No
Instruments and Electrics
-
12v Socket
No
-
Instruments
5 inch TFT Panel Multi information display
-
Tail Light
LED
-
Connectivity
RoadSync
-
USB Socket
Type - C
-
Self Cancelling Indicators
Yes
-
Headlights
LED
Additional Features
-
Riding Modes
Sport, Standard, Rain, Gravel and User Mode
-
Additional Features
ESS
Key Features
-
Connectivity
HSVCs
-
Riding Modes
5 Riding Modes with ABS cancel
-
Emergency Stop Signal
Yes
-
Self Cancelling Indicators
Yes
-
12v Socket
Optional
-
USB Socket
Type C
-
Quick Shifter
Optional
Engine
-
Bore × Stroke (mm)
87mm x 63.5mm
-
Carburation
PGM-FI electronic injection
-
Compression Ratio
11.0:1
-
Engine Displacement (cc)
755
-
Engine Type
Liquid-cooled OHC 4-stroke 8-valve Parallel Twin with 270° crank and uni-cam
-
Max. Power Output
67.5kW @ 9,500rpm
-
Max. Torque
75Nm @ 7,250rpm
-
Starter
Electric
-
C02 Emissions (g/km)
103 g/km
-
Oil Capacity (Litres)
3.9L
Wheels
-
ABS System
2 channel
-
Brakes Front
Dual 310mm x 4.5mm disc with axial mount 2 piston calipers
-
Brakes Rear
Single 256mm x 6.0mm disc with single piston caliper
-
Suspension Front
Showa 43mm SFF-CA USD, 200mm travel
-
Suspension Rear
Separate pressure, Pro-Link swingarm, 190mm travel
-
Tyre Size Front
90/90-21M/C 54H
-
Tyre Size Rear
150/70R18M/C 70H
-
Wheels Front
Stainless spoke, Aluminium rim, Tube type
-
Wheels Rear
Stainless spoke, Aluminium rim, Tube type
Dimensions and Weights
-
Battery Capacity (VAh)
12v 8.6Ah
-
Caster Angle
27˚
-
Dimensions (L×W×H) (mm)
2,325mm x 838mm x 1,450mm
-
Frame type
Steel diamond
-
Fuel Tank Capacity (Litres)
16.9L
-
Fuel Consumption
23km/l
-
Ground Clearance (mm)
210mm
-
Kerb Weight (kg)
208kg
-
Seat Height (mm)
850mm
-
Trail (mm)
111mm
-
Wheelbase (mm)
1,560mm
-
Turning Radius
2.6m
-
Noise Level
Lwot - 79.4; Lurban - 75
Transmission
-
Clutch
Wet multiple, Assisted slipper clutch
-
Final Drive
Chain
-
Gearbox
6 speed Manual Transmission
-
Quick Shifter
Optional
Instruments and Electrics
-
12v Socket
Optional
-
Instruments
TFT
-
Tail Light
LED
-
Connectivity
HSVCs
-
USB Socket
Type C
-
Self Cancelling Indicators
Yes
-
Emergency Stop Signal
Yes
-
Security
HISS
Additional Features
-
Riding Modes
5 Riding Modes with ABS cancel
