Specifications and Price
Compare
Key Specs
-
Battery Capacity (VAh)
12-9.1Ah YTZ10S
-
Dimensions (L×W×H) (mm)
2,030mm x 685mm x 1140mm
-
Fuel Consumption
18.2km/L [5.5L/100km]
-
Engine Type
Inline-4, Liquid cooled 16-valve DOHC
Engine
-
Bore × Stroke (mm)
67x42.5
-
Carburation
PGM-FI
-
Compression Ratio
12.2:1
-
Engine Displacement (cc)
599
-
Engine Type
Inline-4, Liquid cooled 16-valve DOHC
-
Max. Power Output
89kW [119hp] / 14,250rpm
-
Max. Torque
63Nm / 11,500rpm
-
C02 Emissions (g/km)
128 g/km
-
Oil Capacity (Litres)
3.4L
Wheels
-
ABS System
2 channel
-
Brakes Front
310mm floating discs with radial-mount 4-piston caliper
-
Brakes Rear
220mm disc with 1-piston caliper
-
Suspension Front
Fully adjustable Showa 41mm Big Piston USD, 120 mm stroke.
-
Suspension Rear
Fully adjustable Showa rear shock operating through Pro-Link. 128mm axle travel.
-
Tyres Front
DUNLOP Roadsports2
-
Tyre Size Front
120/70ZR17M/C
-
Tyre Size Rear
180/55ZR17M/C
-
Tyres Rear
DUNLOP Roadsports2
-
Wheels Front
17M/CxMT3.50
-
Wheels Rear
17M/CxMT5.50
Dimensions and Weights
-
Battery Capacity (VAh)
12-9.1Ah YTZ10S
-
Caster Angle
24 o 06’
-
Dimensions (L×W×H) (mm)
2,030mm x 685mm x 1140mm
-
Frame type
Aluminium twin tube composite twin spar
-
Fuel Tank Capacity (Litres)
18L
-
Fuel Consumption
18.2km/L [5.5L/100km]
-
Ground Clearance (mm)
125mm
-
Kerb Weight (kg)
193kg
-
Seat Height (mm)
820
-
Trail (mm)
100mm
-
Wheelbase (mm)
1370
-
Noise Level
Lurban - 74dB, Lwot - 77dB
Transmission
-
Clutch
Wet, multiplate hydraulic clutch
-
Final Drive
Chain
-
Transmission Type
Manual 6-speed
-
Quick Shifter
Yes
Instruments and Electrics
-
Headlights
LED
-
Instruments
TFT meter
-
Tail Light
LED
-
Security
HISS
