PCX125 2021

PCX125 2021



PCX125 2021 key features

PCX125 2021 Specifications

Show specifications

  • Engine
    Bore × Stroke (mm) 53.5 x 55.5mm
    Carburation PGM-FI electronic fuel injection
    Compression Ratio 11.5:1
    Engine Displacement (cc) 125cc
    Engine Type Single-cylinder, water cooled, eSP+ SOHC 4-stroke
    Max. Power Output 9.2kW / 8,750rpm
    Max. Torque 11.8Nm / 6,500rpm
    Starter Electric
    C02 Emissions (g/km) 47 g/km
    Oil Capacity (Litres) 0.9 L
  • Wheels
    Brakes Front 220mm hydraulic disc with combined 2 piston caliper
    Brakes Rear 130mm drum
    Suspension Front 31mm telescopic fork, 89mm axle travel
    Suspension Rear Twin suspension aluminium swingarm, 95mm axle travel
    Tyre Size Front 110/70-14M/C (48P)
    Tyre Size Rear 130/70-13M/C (61P)
    Wheels Front 14M/C x MT2.75, 5-spoke cast aluminium
    Wheels Rear 14M/C x MT3.50, 5-spoke cast aluminium
  • Dimensions and Weights
    Battery Capacity (VAh) 12V/7AH (10H)
    Caster Angle 27°
    Dimensions (L×W×H) (mm) 1,935 x 740 x 1,105mm
    Frame type Tubular steel duplex
    Fuel Tank Capacity (Litres) 8.1 L
    Fuel Consumption 47.6 km/L (without Idling Stop)
    Ground Clearance (mm) 135mm
    Kerb Weight (kg) 130kg
    Seat Height (mm) 764mm
    Trail (mm) 80mm
    Wheelbase (mm) 1,315mm
  • Transmission
    Clutch Automatic, centrifugal, dry type
    Final Drive V-belt
    Transmission Type V-Matic
  • Instruments and Electrics
    Headlights LED
    Instruments LCD
    Tail Light LED
    USB Socket Yes
    Security Immobiliser
