Engine

• Engine Displacement (cc) 49
• Compression Ratio (X:1) 10:1
• Bore × Stroke (mm) 39 x 41.4
• Engine Type Air-cooled 4-stroke 2-valve SOHC single
• Starter Kick

Wheels

• Brakes Front 80mm leading/trailing drum
• Brakes Rear 80mm leading/trailing drum
• Tyre Size Front 2.50 10 (33)
• Tyre Size Rear 2.50 10 (33)
• Wheels Front Steel rim/wire spoke
• Wheels Rear Steel rim/wire spoke

Dimensions and Weights

• Dimensions (L×W×H) (mm) 1,302 x 581 x 774

Transmission

• Gearbox 3-speed with automatic clutch

Instruments and Electrics

• Ignition System Capacitor discharge (CDI)

Drivertrain

• Final Drive Roller Chain

Chassis

• Frame Type Mono-backbone; steel tube
• Wheelbase (mm) 911
• Seat Height (mm) 548
• Ground Clearance (mm) 146
• Caster Angle (degrees) 25°
• Trail (mm) 32
• Kerb Weight (kg) 50

Fuel System

• Carburation 11mm Piston-Valve Carburetor
• Fuel Tank Capacity (L) 2.6 litres (including reserve)

Suspension

• Suspension Front: Type 21.7mm inverted telescopic fork, 87mm axle travel
• Suspension Rear: Type Monoshock with cantilever-type swingarm, 70mm axle travel
