Montesa Cota 300RR Specs | Off Road Specifications | Honda UK


Your bike in detail

Race Ready.

£7 599

Montesa Cota 300RR 2018 key features

Montesa Cota 300RR 2018 Specifications

Show specifications

  • Engine
    Bore × Stroke (mm) 80 × 57.2 mm
    Carburation Electronic fuel injection PGM-FI
    Compression Ratio 10.4: 1
    Engine Displacement (cc) 288
    Engine Type (cm³) Single, 4-strokes, 4 valves, SOHC, liquid cooled
    Starter Kick starter
  • Wheels
    Brakes Front 185 x 3.5 mm hydraulic disc with 4-piston caliper and sintered metal pads
    Brakes Rear 150 x 2.5 mm hydraulic disc with 2-piston caliper and sintered metal pads
    Suspension Front 39 mm TECH telescopic fork with aluminum tubes and spring preload, compression and rebound adjustment. 167mm
    Suspension Rear Pro-Link system with SHOWA shock with spring preload and rebound adjustment. 170mm stroke
    Tyres Front Front 80/100 21 (Michelin)
    Tyres Rear Rear 120/100 R18 (Michelin)
    Wheels Front Aluminium rims/ wire spokes
    Wheels Rear Aluminium rims/ wire spokes
  • Dimensions and Weights
    Caster Angle 23°
    Dimensions (L×W×H) (mm) 2,016 × 830 × 1,130 mm
    Frame type Diamond, aluminum twin spar
    Fuel Tank Capacity (Litres) 1.9 litres
    Ground Clearance (mm) 335 mm
    Seat Height (mm) 650 mm
    Trail (mm) 63 mm
    Wheelbase (mm) 1321 mm
  • Transmission
    Clutch Hydraulic
    Final Drive Roller chain
    Transmission Type 5-speed
  • Instruments and Electrics
    Ignition System Electronic, digital transistor
