Key Specs

• Battery Capacity (V / Ah) 12-Jun-2026
• Fuel Consumption (L / 100 km) 4.5

Engine

• Cooling Type Liquid
• SOHC or DOHC DOHC
• Configuration Inline
• Number of Cylinders 4
• Number of Valves per cylinder 4
• Engine Displacement (cc) 502
• Bore (mm) 60
• Stroke (mm) 44.4
• Compression Ratio (X:1) 12.3
• Max. Torque (Nm @ rpm) 46.3 @ 10,500
• Stationary Noise Level (dB) 75.2
• Max. Speed (km/h) 210
• Oil Capacity (L) 3.2

Wheels

• Wheel Dimension: Front 17M/C x MT3.5
• Wheel Dimension: Rear 17M/C x MT4.5
• Wheel Type Cast
• Tyres Front 120/70/ZR17
• Tyres Rear 160/60/ZR17
• Tyre Make / Type Pirelli

Instruments and Electrics

• Meter Type TFT
• Meter Size (inches) 5
• Connectivity RoadSync
• USB socket USB-C
• Security System HISS (Honda Ignition Security System)
• Alarm Optional

Additional Features

• Top Box Capacity (L) n/a
• Panniers Capacity (L) n/a
• Other Features Ram air

Drivertrain

• Clutch Type Wet Multiplate & Assisted Slipper
• Transmission Type E-Clutch
• Number of Gears 6
• Final Drive Chain

Brakes

• ABS Type 2-channel ABS
• Front Brake Discs: number 2
• Front Brake Discs: size (mm) 296
• Front Brake Calipers: Type 2-piston radial mounted
• Front Brake Calipers: Make Nissin

Rider Aids

• Throttle-by-Wire (TBW) Yes
• Selectable Riding Modes (number and type) 5 modes (Standard, Sport, Urban + 2 user modes)
• Honda Selectable Torque Control (HSTC) Yes
• Wheelie Control Yes

Lighting

• Battery Type AGM
• Battery Capacity (V / Ah) 12-Jun-2026
• Headlight / Taillight LED / LED
• Emergency Stop Signal (ESS) Yes

Chassis

• Frame Type Twin Tube
• Frame Shape Diamond
• Frame Material Steel
• Frame Weight (kg) 14
• Dimensions: Length (mm) 2081
• Dimensions: Width (mm) 758
• Dimensions: Height (mm) 1145
• Wheelbase (mm) 1408
• Handlebar Height (mm) 906
• Seat Height (mm) 780
• Ground Clearance (mm) 135
• Caster Angle (degrees) 25
• Trail (mm) 99
• Turning radius (m) 2.9
• Kerb Weight (kg) 189
• Total Kerb Weight with Panniers (kg) n/a
• Maximum Laden Mass Weight (kg) 367
• Integrated Storage (L) n/a

Fuel System

• Carburation PGM FI electronic fuel injection
• Fuel Tank Capacity (L) 14
• CO2 Emissions WMTC (g / km) 105
• Fuel Consumption (L / 100 km) 4.5

Suspension

• Suspension Front: Type USD
• Suspension Front: Brand KYB
• Suspension Front: Fork Diameter (mm) 41
• Suspension Front: Stroke length (mm) 120
• Suspension Front: Travel length (mm) 109
• Suspension Rear: Type Monoshock
• Suspension Rear: Brand Other
• Suspension Rear: Stroke length (mm) 52.5
• Suspension Rear: Travel length (mm) 119
• Suspension Rear: Adjustment? Pre-load
• Swingarm Type Pro-Link
• Swingarm Material Aluminium
