Specifications

Your Foreman in detail

Select an ATV to display specification details.

TRX520FM2

Change variant (3)

Foreman 4x4 EPS - 5fwd/1rev Manual foot-shift.


£9,730.00*

(exc. VAT)

Patriot Red

Change colour (1)

TRX520FM2 Key Features

TRX520FM2 Specifications ▲

Show specifications

  • Specification
    Classification Heavy duty ATV
    Engine 518cc liquid cooled, wet-sump, longitudinally mounted OHV four-stroke single-cylinder
    Carburation PGM-FI 36mm
    Ignition Full-transistorised with electronic advance
    Starter Electric
    Transmission Auto clutch with manual shift; 5 speed and reverse
    Drive 4wd Direct driveshafts with TraxLok™ switchable 2wd/4wd and locking front differential.
    Front Suspension Independent double-wishbone; 185mm travel
    Rear Suspension Swingarm with single shock; 185mm travel
    Power Steering Yes
    Front Brakes 190mm dual hydraulic discs
    Rear Brake 170mm sealed mechanical drum
    Front tyres 25 x 8-12
    Rear tyres 25 x 10-12
    Fuel Capacity (l) 14.7L, incl. 4.9L res.
    Bore x Stroke (mm) 96.0 x 71.5
    Dimensions - Length (mm) 2185
    Dimensions - Width (mm) 1204
    Dimensions - Height (mm) 1237
    Wheelbase (mm) 1270
    Seat Height (mm) 924
    Ground Clearance (mm) 248
    Towing Capacity (kg) 384
    Front Rack Capacity (kg) 99 pounds
    Rear Rack Capacity (kg) 187 pounds
