Honda Foreman TRX500 Specifications

Your Foreman in detail

Select an ATV to display specification details.

TRX500FA6

Change variant (4)

Foreman DCT IRS PS 2/4wd - 5 fwd/1rev automatic with high/low gear ratios and electric shift (ESP).


£8 330*

(exc. VAT)

Patriot Red

Change colour (1)

TRX500FA6 Key Features

TRX500FA6 Specifications ▲

Show specifications

  • Specification
    Engine 475cc liquid cooled, wet sump, longitudinally mounted OHV 4-stroke single cylinder
    Carburation PGM-Fi 36mm throttle-body fuel injection system
    Ignition Full-transistorized with electronic advance
    Starter Electric with auxiliary recoil
    Transmission Automatic transmission (Dual Clutch) with five forward gears with reverse, auto-shifting or electric shift
    Drive Direct front and rear driveshafts with TraxLok™ 2/4wd selection and pushbutton front differential lock.
    Front Suspension Independent double-wishbone 185mm travel, preload adjustable
    Rear Suspension Independent double-wishbone 185mm travel, preload adjustable
    Power Steering Yes
    Front Brakes 190mm dual hydraulic discs
    Rear Brake 170mm single hydraulic/mechanical disc
    Front tyres 25 x 8-12 radial
    Rear tyres 25 x 10-12 radial
    Fuel Capacity (l) 14.7L, incl. 4.9L reserve
    Bore x Stroke (mm) 92.0 × 71.5 mm
    Dimensions - Length (mm) 2147
    Dimensions - Width (mm) 1205
    Dimensions - Height (mm) 1237
    Wheelbase (mm) 1292
    Seat Height (mm) 911
    Ground Clearance (mm) 241
    Towing Capacity (kg) 600
    Front Rack Capacity (kg) 45
    Rear Rack Capacity (kg) 85
