Specifications

Your bike in detail

Sleek, urban design for a modern lifestyle. With compact, retro-minimal Neo Sports Café styling, full LED lighting, an addictive four-cylinder engine and a sharp-handling chassis.



Candy Chromosphere Red

Choose colour (4)

CB650R Neo Sports Café 2019 key features

CB650R Neo Sports Café 2019 Specifications ▲

Show specifications

  • Engine
    Bore × Stroke (mm) 67mm x 46mm
    Carburation PGM-FI electronic fuel injection
    Compression Ratio 11.6:1
    C02 Emissions 112
    Engine Displacement (cc) 649cc
    Engine Type (cm³) Liquid-cooled 4-stroke 16-valve DOHC inline-4 cylinder
    Max. Power Output 70kW/12,000rpm
    Max. Torque 64Nm/8,500rpm
    Starter Electric
    Throttle Bore 32
  • Wheels
    ABS System 2 channel
    Brakes Front 310 mm x 4.5 mm disc with four piston caliper
    Brakes Rear 240 mm x 5 mm disc with single piston caliper
    Suspension Front Showa separate function fork (SFF) USD
    Suspension Rear Mono with 10 stage pre-load adjuster, Aluminium Cast swingarm
    Tyre Size Front 120/70ZR17 M/C (58W)
    Tyre Size Rear 180/55ZR17 M/C (73W)
    Wheels Front 17M/C X MT3.50 Multi-Spoke Cast Aluminium
    Wheels Rear 17M/C X MT5.50 Multi-Spoke Cast Aluminium
  • Dimensions and Weights
    Battery Capacity (VAh) YTZ10/FTZ10S 8.6Ah MF
    Caster Angle 25.5°
    Dimensions (L×W×H) (mm) 2,130mm X 780mm X 1,075mm
    Frame type Steel diamond
    Fuel Tank Capacity (Litres) 15.4L
    Fuel Consumption 20.4km/litre
    Ground Clearance (mm) 150mm
    Kerb Weight (kg) 202kg
    Seat Height (mm) 810mm
    Trail (mm) 101mm
    Wheelbase (mm) 1,450mm
  • Transmission
    Clutch Wet multiplate, A.S.clutch
    Final Drive Chain
    Gearbox 6-speed
  • Instruments and Electrics
    Headlights LED
    Ignition System Full transisterized
    Instruments Digital Speedometer, Digital Bar Graph Tachometer, Dual Trip Meters, Digital Fuel Level Gauge & Fuel Consumption Gauge, Digital Clock, Water Temp, Gear position, Shift UP Indicator
    Tail Light LED

▲
